5/8" – ER16, - 60mm, hex nut

Part Number: 82804832
Manufacturers Name: Techniks, Inc.
Manufacturers Part #: 4832
$105.12
$105.12 EA
Quantity EA
ADD TO CARTQUOTE VOLUME DISCOUNT

Product Details

5/8" – ER16, - 60mm, hex nut Techniks Collet Chuck Extensions are made with precision to achieve T.I.R. of 0.0001" or less.
Specifications
  • Overall Diameter (in): 0.625
  • Type: 5/8" – ER16, - 60mm, hex nut
  • Body Dia-Workpiece Side (in): 1.102
  • Overall Diameter (mm): 15.88
  • Body Dia-Workpiece Side (mm): N28
  • Material: 8620 Steel
  • Unit of Tool: Metric or Inch
  • Lock Nut Diameter (in): 1.26
  • Style: Single Ended
  • Lock Nut Diameter (mm): N32
  • Gage Length (in): 1.382
  • Taper: 5/8" Straight Shank
  • Gage Length (mm): 35.1
  • Gage Length-Face Contact (in): N/A
  • Gage Length-Face Contact (mm): N/A
  • Capacity Range (in): 0.019" - 0.41"
  • Capacity Range (mm): 0.5 - 10.5mm
  • Overall Length (in): 3.74
  • Balanced to: N/A
  • Overall Length (mm): 95
