ISO 30 – ER40 - CMS toolholder

Part Number: 82812040-CMS

Manufacturers Name: Techniks, Inc.

Manufacturers Part #: 12040-CMS

$316.80

$316.80 EA

Quantity EA

ADD TO CART QUOTE VOLUME DISCOUNT

Product Details

ISO 30 – ER40 - CMS toolholder Techniks Collet Chucks are balanced to 25,000 RPM at G2.5 tolerance. Individually lab tested for accuracy and balance, includes performance report. Techniks holders achieve 0.0001" or less T.I.R.. Taper is ground to AT3 accuracy or better.

Specifications

Overall Diameter (in): 1.81
Type: ISO 30 – ER40 - CMS toolholder
Overall Diameter (mm): N46
Body Dia-Workpiece Side (in): 2.48
Body Dia-Workpiece Side (mm): N63
Material: 8620 Steel
Unit of Tool: Metric or Inch
Lock Nut Diameter (in): 2.48
Style: Single Ended
Lock Nut Diameter (mm): N63
Gage Length (in): 2.6
Gage Length (mm): N66
Taper: ISO30
Gage Length-Face Contact (in): 2.47
Gage Length-Face Contact (mm): 62.8
Capacity Range (in): 0.086" - 1.02"
Capacity Range (mm): 2.2 - 26mm
Overall Length (in): 4.48
Balanced to: 25,000 RPM at G2.5
Overall Length (mm): 113.8
