ER16 Collets (metric) – Shank Sizes: 7–8

Part Number: 82804216-08
Manufacturers Name: Techniks, Inc.
Manufacturers Part #: 04216-08
$18.60
$18.60 EA
Quantity EA
ADD TO CARTQUOTE VOLUME DISCOUNT

Product Details

ER16 Collets (metric) – Shank Sizes: 7–8 Techniks Precision Collets have at most .0002" T.I.R. as a standard quality guarantee. Their clamping range is .039". For best results, use with a PowerCOAT Nut to improve holding power and extend tool life.
Specifications
  • Series: ER16
  • Capacity (in): 0.315 - 0.2756
  • Capacity (mm): 8 - 7
  • Type2: Precision Spring Collet
  • Unit of Tool: Metric
  • Number of Pieces: N/A
  • Incremental Division: N/A
  • Style: Single Angle
  • Shank Size (in): 0.315
  • Shank Size (mm): N8
  • Square Size (in): N/A
  • Square Size (mm): N/A
  • Tap Range (in): N/A
  • Tap Range (mm): N/A
  • Tap Size (in): N/A
  • Tap Size (mm): N/A
  • Overall Length (in): 1.083
  • Overall Length (mm): 27.5
