CAT40 – ER32 - 4" DualDRIVE

Part Number: 82846.122.32.400

Manufacturers Name: Techniks, Inc.

Manufacturers Part #: 46.122.32.400

$208.08

$208.08 EA

Quantity EA

ADD TO CART QUOTE VOLUME DISCOUNT

Product Details

CAT40 – ER32 - 4" DualDRIVE DualDRIVE are compatible with Dual-Contact spindles and standard. Offers improved rigidity and T.I.R.. Balanced to 25,000 RPM at G2.5 tolerance. Each holder is lab certified and has a individual report. Coolant through spindle or flange (DIN B).

Specifications

Overall Diameter (in): 2.5
Type: CAT40 – ER32 - 4" DualDRIVE
Body Dia-Workpiece Side (in): 1.969
Overall Diameter (mm): 63.5
Body Dia-Workpiece Side (mm): N50
Material: 8620 Steel
Unit of Tool: Metric or Inch
Lock Nut Diameter (in): 1.97
Style: Single Ended DualDRIVE
Lock Nut Diameter (mm): N50
Gage Length (in): N4
Gage Length (mm): 101.6
Taper: CAT40
Gage Length-Face Contact (in): 3.87
Gage Length-Face Contact (mm): 98.4
Capacity Range (in): 0.043" - 0.83"
Capacity Range (mm): 1.1 - 21mm
Overall Length (in): 6.68
Balanced to: 25,000 RPM at G2.5
Overall Length (mm): 169.7
