#5 x 82 DEG CARB DRILL/C-SINK, AlTiN

Part Number: 33625670-C3
Manufacturers Name: Solid Carbide Center Drills
Manufacturers Part #: 25670-C3
$91.55
$91.55 EA
Quantity EA
ADD TO CARTQUOTE VOLUME DISCOUNT

Product Details

0.1875" (3/16) Drill DIA x 82° Included Carbide #5 Combined Drill & Countersink DE, 2 Flutes, AlTiN Coated
Features
  • This product can expose you to chemicals including cobalt which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
Specifications
  • Profile: Drill
  • Metric Flag: 0
  • Flute Count: 82
  • Point Angle: 118
  • Overall Length: 2.7500" (2-3/4)
  • Shank Diameter: 0.4375" (7/16)
  • Length of Cut: 0.3870"
  • Size: N5
  • Included Angle: 82
  • Angle Per Side: N41
  • Drill Length: 0.1870" (3/16)
  • Drill Diameter: 0.1875" (3/16)
